Cotton fabric laminate SRBF Material - Vole Brand

Cotton fabric laminate

Medium/fine weave cotton/phenolic resin laminated plastic

(SRBF – Synthetic Resin Bonded Fabric)

Vole Brand Tufnol is a medium/fine weave grade for mechanical applications, where the finish requirements or shape of the component demand a slightly finer reinforcement than other general purpose grades.

It is excellent for screw threading and for other parts where good machining qualities are needed.

It is suitable for electrical insulation at low voltages.

What is Vole Brand used for?

Vole Brand is used for mechanical applications where good machined finish is important, but where the benefits of the finest weave grades are not considered necessary, for example, medium/fine gears, threaded items, blades, wear resistant components and many similar items.

Application

  • A medium/fine grade for mechanical applications.
Close-up of several brown, circular metal bands with holes and slots, stacked together on a white background, shown alongside Cotton Fabric Laminates SRBF for comparison.

Format

Types AvailableSheetsSheet (RFS)TubesOther Sections
Natural colour Vole brand✓✓✓✓
Table showing that natural colour Vole brand SRBF Material is available in sheets, rods, and tubes, but not other sections.

View/Download Datasheet(s):

Blue and gray Tufnol brochure cover with white lines, geometric shapes, and a subtle nod to Cotton Fabric Laminates SRBF.
DATASHEET
A blue and grey Tufnol-branded document featuring white lines symbolizing text, with the logo in the top left corner, referencing Cotton Fabric Laminates SRBF for added material context.
SAFETY DATASHEET

Standards

  • Sheet: BS EN 60893-3-4 Type PF CC 203
  • Rod from Sheet: BSEN 60893-3-4:2012 PF CC 203
  • Round Tube: BS EN 61212-3-2 Type PF CC 33
  • NEMA Sheet: NEMA LI-1-1983 Type L

*Testing and certification to these standards is subject to special enquiry.   Standard quality testing is to British Standards.
