SRBF Laminated Fabrics - Whale Brand
Cotton fabric laminate
Medium weave cotton/phenolic resin laminated plastic
(SRBF – Synthetic resin Bonded Fabric)
A general purpose grade for mechanical applications.
Whale Brand Tufnol is a good, general-purpose medium weave grade for mechanical applications. It has excellent all round physical properties with strength, good toughness and wear resistance. It is used for electrical insulation at low voltages only.
What is Whale Brand used for?
Whale Brand is a most useful general purpose material and is the most popular grade for a wide range of mechanical applications and general uses, such as gears, spacers, jigs and fixtures, wear resistant components, low voltage insulation and many others.
Application
- A general purpose grade for mechanical applications.
Format
| Types Available | Sheets | Sheet (RFS) | Tubes | Other Sections |
|---|---|---|---|---|
| Natural colour | ✓ | ✓ | ✓ | ✓ |
| Black Whale Brand | ✓* | X | X | X |
| Graphite-impregnated Carp Brand | ✓* | ✓* | ✓* | ✓* |
* Minimum quantity orders may apply
View/Download Datasheet(s):
Standards
- Sheet: BS EN 60893-3-4 Type PF CC 203
- Rod from Sheet: BS EN 60893-3-4:2012 PF CC 203
- Rectangular Bar: BS 6128 Part 4 Type PF CC 43
- Hexagon Bar: BS 6128 Part 6 Type PF CC 63
- Round Tube: BS EN 61212-3-2 Type PF CC 33
- Rectangular Tube: BS 6128 Part 13 Type PF CC 131
- NEMA Sheet: NEMA LI-1-1983 Type LE
- DIN Round Rod and Tube: DIN 7735 TYPE Hgw 2088 & 2089
*Testing and certification to these standards is subject to special enquiry. Standard quality testing is to British Standards.
