Tufnol SRBGF Material - Grades 10G/40, 10G/41, 10G/42 and 10G/44
Epoxy Glass Fabric laminate sheets and tubes
Glass fibre/epoxide resin laminated plastic
(SRBGF – Synthetic Resin Bonded Glass Fabric)
Top quality materials for mechanical and electrical applications.
The Tufnol range of high quality epoxy resin bonded glass fabric laminates offer very high mechanical strength and low moisture absorption, combined with excellent electrical properties, under both dry and humid conditions. They are rigid materials with good dimensional stability and good resistance to a wide range of working environments.
Four standard grades are available:
- Tufnol Grade 10G/40 – The most widely used grade, suitable for continuous use at temperatures up to approximately 130ºC. (Class B).
- Tufnol Grade 10G/41 – Similar to 10G/40, but with comtrolled flammability
- Tufnol Grade 10G/42 – Made with an epoxy resin which offers increased mechanical strength at higher temperatures. Suitable for uses up to 155 ºC (Class F).
- Tufnol Grade 10G/44 – Similar to Grade 10G/42, but with improved retention of strength after heat ageing.
Application
-
These high performance materials are used for a very wide variety of applications where high strength, rigidity dimensional stability and electrical performance are required. Tufnol epoxy glass laminate sheets and tubes are typically used in applications such as insulation for large turbine generators, components for cryogenic superconducting magnets, high strength bolt insulation in structures, jigs for electro-chemical machining and structural insulation for high performance electronic equipment.
However, due to the abrasive nature of the high glass fibre content, epoxy glass grades are not normally selected for wearing or bearing applications.
Format
| Types Available | Sheets | Sheet (RFS) | Tubes | Other Sections |
|---|---|---|---|---|
| Grade 10G/40 – Natural colour | ✓ | ✓ | X | X |
| Grade 10G/41 – Natural colour | ✓ | X | X | X |
| Grade 10G/42 – Natural colour | ✓ | X | X | X |
| Grade 10G/44 – Natural colour | ✓ | X | X | X |
View/Download Datasheet(s):
Standards
- Grade 10G/40 Sheet: BS EN 60893-3-2 Type EP GC 201
- Grade 10G/40 Round Rod (Rolled & moulded): BS EN 61212-3-3 Type EP GC 41 & 42
- Grade 10G/41 Sheet: BS EN 60893-3-2 Type EP GC 202
- Grade 10G/42 Sheet: BS EN 60893-3-2 Type EP GC 203
- Grade 10G/44 Sheet: BS EN 60893-3-2 Type EP GC 203 & BS 3953 Type EP-7
- Grade 10G/40 Rod from Sheet: BS EN 60893-3-2:2011 EP GC 201
- Grade 10G/41 Rod From Sheet: BS EN 60893-3-2:2011 EP GC 202
- Grade 10G/42 Rod from Sheet: BS EN 60893-3-2:2011 EP GC 203
- Grade 10G/44 Rod from Sheet: BS 3953: 1990 EP7
*Testing and certification to these standards is subject to special enquiry. Standard quality testing is to British Standards.
